Mobile Signal Booster – Tri-Band – 1000 sqm (Power Line)

(Optus)

Bestseller Mobile Signal Booster – Tri-Band – 1000 sqm (Power Line)
  • Application:

    3 Band
  • Coverage:

    Up to 1000 sqm
  • Ideal For:

  • Provider:

  • Frequency:

    900/1800/2100 MHz
  • Data:

    3G & 4G & Calls
Free Trackable Delivery In AU Delivery time: 5-7 Business Days

Benefits and Features:

  • Instant Signal Boost of up to 5 bars
  • CE & RoHS ISO Certified Product
  • Easy Installation
  • Instant Technical Assistance
  • 2 -Year Warranty

$ 1590

Units Sold: 1140

Free Shipping

Overview

Kit includes:

  • 1x repeater
  • 1x outdoor LPDA antenna
  • 2x indoor antenna
  • 1x power adapter
  • 1x 15 meters cable
  • 2 x 5 meters cable
  • 2 x 10 meters cable
  • 1x1 meters cable
  • 2 way splitter
We provide 2 Years warranty on all our products
Select Option
If our standard package cable lenght is not enought to cover your area you have an upgrade option.
Upgrade your booster kit with our internal antenna for optimal performance in larger spaces.
Price Match Guarantee

Doing business in remote areas of the country can be challenging for many reasons. One of those reasons is an extremely poor connection. To fix the problem with your mobile data signal, check out this powerful device! The installation is not as challenging as you might think. You’ll find all of the necessary parts in the set-up kit, along with step-by-step instructions, which will guide you through the whole process, so no special tools or professional skills are required. But if you do feel lost at any moment, contact our 24/7 customer support line and our staff will be happy to help! You have literally no downside with our product. It will be delivered to you for free, along with a 2-year warranty and if, for any reason, you are not happy with the result, feel free to return your purchase within 30 days for a full refund.

  • Technical Sheet
  • Coverage
    Up to 1000 sqm
  • Use
    Overlarge Home
    Overlarge Office
    Large Hotel
  • Operator
    Yes Optus (3G & 4G)
    Vodafone (3G & 4G)
  • Frequency
    900/1800/2100 MHz
  • Number of simultaneous users
    50
  • Up-link
    890 ~ 915 MHz
    1710 ~ 1785 MHz
    1920 ~ 1980 MHz
  • Down-link
    935~ 960 MHz
    1805~ 1880 MHz
    2110 ~ 2170 MHz
  • Voltage
    AC90-264V,output DC 5V / 3A
  • Size (Length x Width x Height)
    35 x23 x5 cm.
  • Weight (Booster unit only)
    5.8 KG.
  • Frequency
    • Uplink
      890-915 MHz
    • Downlink
      935-960 MHz
    • Bandwidth
      25 MHz
  • DCS
    • Uplink
      1710-1780 MHz
    • Downlink
      1805-1880 MHz
    • Bandwidth
      70 MHz
  • DMA-3G
    • Uplink
      1920-1980 MHz
    • Downlink
      2110-2170 MHz
    • Bandwidth
      60 MHz
  • Max Gain
    • Uplink
      60 ±2 dB
    • Downlink
      65 ±2dB
    • Bandwidth
      25MHz&75MHz&60MHZ
  • Bandwidth
    25 MHz
  • Ripple in Band
    ≤8dB
  • Max. Input Power Without Damage
    0dBm
  • Output Power
    • Uplink
      20dBm
    • Downlink
      23dBm
  • Noise Figure @ max. gain
    • Uplink
      8db
    • Downlink
      14db
  • Return loss
    ≤-8 dB
  • Auto Level Control
    30dBm
  • MGC
    31db@1dB/step
  • Time Delay
    ≤ 5μs
  • MTBF
    > 50000 hours
  • Power Supply
    AC:110~240V, 50/ 60Hz;DC:5V 3A
  • Power Consumption
    12.5W
  • Impedance
    50 Ω
  • RF Connector
    N -Female
  • Cooling
    Heat sink Convection cooling
  • Installation Type
    Wall Installation
  • Environment Conditions
    IP40
  • Humidity
    <90%
  • Operating Temperature
    -10°C ~ 55°C
  • Power
    • Red
      Normal
    • Off
      DC power problem
  • DL (Downlink)
    • White
      No signal received Solution: Adjust the outdoor installation to get sound signal
    • Green
      Signal received ok but not perfect
    • Red
      Full signal received
  • UP (Uplink))
    • Flicker
      When there is a call it is normal
    • Green
      Always green means self-excited Solution: Turn off the booster, adjust the indoor and outdoor antenna again and try to expand the distance or create some barriers between them.
