Single Band Mobile Signal Booster - 3G – 300 sqm

(All AU Operators)

  • Application:

    1 Band
  • Coverage:

    up to 300 sqm
  • Ideal For:

  • Provider:

  • Frequency:

    2100MHz
  • Data:

    3G
Free Trackable Delivery In AU Delivery time: 5-7 Business Days

Benefits and Features:

  • Instant Signal Boost of up to 5 bars
  • CE & RoHS ISO Certified Product
  • Easy Installation
  • Instant Technical Assistance
  • 2 -Year Warranty

$ 440

Units Sold: 1820

Free Shipping

Overview

Kit includes:

  • 1x repeater
  • 1x indoor antenna
  • 1x outdoor Panel antenna
  • 1x power adapter
  • 1x 15 meters cable
  • 1x 5 meters cable



We provide 2 Years warranty on all our products

For better connection add LPDA antenna to your order.
If our standard package cable length is not enough to cover your area you have an upgrade option.
Upgrade your booster kit with our internal antenna for optimal performance in larger spaces.
Price Match Guarantee

In our day and age, not having a full 5-bar mobile connection seems such a waste. Luckily, we have a range of boosters to get you up and running. The ‘Mobile Signal Booster 3G model is a wonderful signal booster that repeats the 2100MHz signal band used by Vodafone, Optus, and Telstra, giving you a solid 5-bar signal every time.

The booster installation is a simple procedure that won’t take you long, as the kit is delivered with everything you need to get connected, free of charge. Our 24/7 support crew has you covered in the rare instances that you do experience an issue during or after setup.

Plus, our products come with a 2-year warranty and if for any reason, you’re not completely satisfied with the device, you can return it within 30 days for a full refund.

  • Technical Sheet
  • Coverage
    up to 300 sqm
  • Use
    Big Boat
    Small Home
    Medium Office
  • Operator
    Vodafone (3G)
    Optus (3G)
    Telstra ( 3G)
  • Frequency
    2100MHz
  • Number of simultaneous users
    50
  • Up-link
    1920 ~ 1980 MHz
  • Down-link
    2110 ~ 2170 MHz
  • Kit
    Repeater and all accessories
  • Voltage
    AC:90~265V, 50/ 60Hz;DC:5V 2A
  • Dimensions
    198*138*30 mm.
  • Weight
    1.1 kg
  • output
    Up link 24dBm Downlink: 27dBm
  • MGC ( Step Attenuation )
    ≥ 31dB / 1dB step
  • Gain Flatness
    GSM & CDMA Tpy≤ 6dB(P-P); DCS,PCS ≤ 8dB(P-P)
    WCDMA ≤ 2dB/ 3.84MHz,Full Band ≤ 5dB(P-P)
  • Noise Figure
    ≤ 5dB
  • Group Delay
    ≤ 2dB
  • Function
    a) Power supply LED denote b) Export power LED denote
  • Automatic Level Control
    50Ω/N connector
  • VSWR
    ≤2dB
  • Frequency Stability
    ≤0.01 ppm
  • Spurious Emission & Output inter-modulation
    GSM Meet ETSI TS 151 026 V 6.1.0
    WCDMA Meet 3GPP TS 25.143 ( V 6.2.0 )
    CDMA Meet IS95 & CDMA2000
  • WCDMA System
    Spurious Emission Mask Meet 3GPP TS 25.143 ( V 6.2.0 )
    Modulation Accuracy ≤ 12.5%
    Peak Code Domain Error ≤ -35dB@Spreading Factor 256
  • CDMA System
    Rho ρ > 0.980
    ACPR Meet IS95 & CDMA2000
  • I /O Port
    N-Female
  • Impedance
    50 ohm
  • Operating Temperature
    -25ºC~+55ºC
  • Environment Conditions
    IP40
  • Dimensions
    155x112x85mm
  • Weight
    ≤ 1.50Kg
  • Power Supply
    Input AC90-264V,output DC 5V / 3A
  • Power LED
    Power Indicator
  • UL LED
    Be lighted when there is phone calling
  • DL 1
    Light is on when Outdoor signal is -65dB
  • DL 2
    Light is on when Outdoor signal only -55dB
  • DL 3
    Light is on when Outdoor signal only -50dB
